New - Build-To-Order Ironcraft 1912 Flex-Wing Cutter | Agricultural Mowers
Have one to sell?
ConditionNew
New
With its smooth top deck and spring suspension, this Flex-Wing Rotary Cutter is ideal for medium-duty applications such as weeds, grass, and brush up to 2” diameter. Designed for use with compact tractors of 35 hp minimum, the cutter requires only one hydraulic outlet. For its 144” cut width, the cutter uses three spindles with two free-swinging blades each, which reduce the shock of impact when a stationary object is contacted. Slip clutches protect the gearboxes and drivelines from damage. Standard equipment includes driveline shields, clutch shields, chain discharge shields and a safety tow chain.
Color Options
Red
Gray
Green
Orange
Blue
Specifications
Recommended Minimum HP: 35 HP
Hitch: Swivel Clevis
Deck Thickness: 10 Gauge
Deck Height: 11 in.
Side Skirt Material: 3/16 in.
Hinge Rods: 1 in.
Suspension: Single Spring
Outboard Gearbox PWR Rating: 75 HP
Splitter Gearbox PWR Rating: 175 HP
Gearbox Rpm: 540 RPM
Blades: 1/2 in. X 3 in. w/ LIFT
Blade Tip Speed: 15,657 FPM
Blade Overlap: 6 in.
Blade Carrier: 3/16 in. Formed Plate With 3/4 in. X 6 in. BAR
Cut Width: 144 in.
Overall Width: 151 in.
Overall Length W/Wheel: 158 in.
Tongue Weight: 759 lb.
Overall Weight: 2630 lb.
Cut Height: 1-1/2 in. - 12 in.
Cutting Capacity: up to 2 in.
Input Pto: Asae Cat 5 Constant Velocity
Wing Drive PTO: Asae Cat 4 With Slip Clutch
Skid Shoes: Replaceable
Chain Shields: Single Row Chain Shields Standard
Towing Safety Chain: Standard
Gearbox Warranty: 5 Yr Limited
Wheel Type: 5 LUG Standard Laminated - Used Aircraft Tires Optional
