GET MUCH MORE THAN YOU PAY FOR.
Don't let its price-point fool you. The Pro-Turn® ZX still delivers great Gravely performance, making it a great value. Its solid construction can handle the toughest commercial jobs and leave a beautifully manicured lawn behind it. This is definitely a "big return on a small investment" situation.
Power Train
Engine Kawasaki® FX691V
Horsepower 22
Engine Displacement 44.3 in / 726 cc
Fuel System Gas
Fuel Capacity 5.1 gal / 19.3 ltr
Drive System Hydro-Gear® ZT-3200™ Transaxles
Brake Type Lever Activated Parking
Driver Position Sit
Ground Speed Forward 8.5 mph / 13.7 kph
Ground Speed Reverse 4 mph / 6.4 kph
Wheels Front 13.0 x 6.5 in - 6.0 in (33.0 x 16.5 cm - 33.0 cm)
Wheels Rear 22.0 x 10.0 in - 12.0 in (55.9 x 25.4 cm - 30.5 cm)
Electric
Battery Capacity 300 CCA
Battery Type Lead Acid - Maintenance Free
Battery Size U1
Deck
Deck Size 60 in / 152.4 cm
Coverage Hour 5.1 acres / 2.1 hectares
Deck Material 7 ga
Deck Construction Fabricated X-Factor® 3
Discharge Configuration Side
Cutting Height Min 1.5 in / 3.8 cm
Cutting Height Max 5 in / 12.7 cm
Cutting Width 60 in / 152.4 cm
Dimensions
Weight (assembled) 931 lb
Length 79 in / 200.7 cm
Width (Chute Up) 56.2 in / 142.7 cm
Width (Chute Down) 67.3 in / 170.9 cm
